Python+Selenium框架设计篇之4-框架内封装基类和实现POM

# coding=utf-8

import time

from selenium.common.exceptions import NoSuchElementException

import os.path

from framework.logger import Logger



# create a logger instance

logger = Logger(logger="BasePage").getlog()





class BasePage(object):

"""

定义一个页面基类，让所有页面都继承这个类，封装一些常用的页面操作方法到这个类

"""



def __init__(self, driver):

self.driver = driver



# quit browser and end testing

def quit_browser(self):

self.driver.quit()



# 浏览器前进操作

def forward(self):

self.driver.forward()

logger.info("Click forward on current page.")



# 浏览器后退操作

def back(self):

self.driver.back()

logger.info("Click back on current page.")



# 隐式等待

def wait(self, seconds):

self.driver.implicitly_wait(seconds)

logger.info("wait for %d seconds." % seconds)



# 点击关闭当前窗口

def close(self):

try:

self.driver.close()

logger.info("Closing and quit the browser.")

except NameError as e:

logger.error("Failed to quit the browser with %s" % e)



# 保存图片

def get_windows_img(self):

"""

在这里我们把file_path这个参数写死，直接保存到我们项目根目录的一个文件夹.\Screenshots下

"""

file_path = os.path.dirname(os.path.abspath(‘.‘)) + ‘/screenshots/‘

rq = time.strftime(‘%Y%m%d%H%M‘, time.localtime(time.time()))

screen_name = file_path + rq + ‘.png‘

try:

self.driver.get_screenshot_as_file(screen_name)

logger.info("Had take screenshot and save to folder : /screenshots")

except NameError as e:

logger.error("Failed to take screenshot! %s" % e)

self.get_windows_img()



# 定位元素方法

def find_element(self, selector):

"""

这个地方为什么是根据=>来切割字符串，请看页面里定位元素的方法

submit_btn = "id=>su"

login_lnk = "xpath => //*[@id=‘u1‘]/a[7]" # 百度首页登录链接定位

如果采用等号，结果很多xpath表达式中包含一个=，这样会造成切割不准确，影响元素定位

:param selector:

:return: element

"""

element = ‘‘

if ‘=>‘ not in selector:

return self.driver.find_element_by_id(selector)

selector_by = selector.split(‘=>‘)[0]

selector_value = selector.split(‘=>‘)[1]



if selector_by == "i" or selector_by == ‘id‘:

try:

element = self.driver.find_element_by_id(selector_value)

logger.info("Had find the element \‘ %s \‘ successful "

"by %s via value: %s " % (element.text, selector_by, selector_value))

except NoSuchElementException as e:

logger.error("NoSuchElementException: %s" % e)

self.get_windows_img() # take screenshot

elif selector_by == "n" or selector_by == ‘name‘:

element = self.driver.find_element_by_name(selector_value)

elif selector_by == "c" or selector_by == ‘class_name‘:

element = self.driver.find_element_by_class_name(selector_value)

elif selector_by == "l" or selector_by == ‘link_text‘:

element = self.driver.find_element_by_link_text(selector_value)

elif selector_by == "p" or selector_by == ‘partial_link_text‘:

element = self.driver.find_element_by_partial_link_text(selector_value)

elif selector_by == "t" or selector_by == ‘tag_name‘:

element = self.driver.find_element_by_tag_name(selector_value)

elif selector_by == "x" or selector_by == ‘xpath‘:

try:

element = self.driver.find_element_by_xpath(selector_value)

logger.info("Had find the element \‘ %s \‘ successful "

"by %s via value: %s " % (element.text, selector_by, selector_value))

except NoSuchElementException as e:

logger.error("NoSuchElementException: %s" % e)

self.get_windows_img()

elif selector_by == "s" or selector_by == ‘selector_selector‘:

element = self.driver.find_element_by_css_selector(selector_value)

else:

raise NameError("Please enter a valid type of targeting elements.")



return element



# 输入

def type(self, selector, text):



el = self.find_element(selector)

el.clear()

try:

el.send_keys(text)

logger.info("Had type \‘ %s \‘ in inputBox" % text)

except NameError as e:

logger.error("Failed to type in input box with %s" % e)

self.get_windows_img()



# 清除文本框

def clear(self, selector):



el = self.find_element(selector)

try:

el.clear()

logger.info("Clear text in input box before typing.")

except NameError as e:

logger.error("Failed to clear in input box with %s" % e)

self.get_windows_img()



# 点击元素

def click(self, selector):



el = self.find_element(selector)

try:

el.click()

logger.info("The element \‘ %s \‘ was clicked." % el.text)

except NameError as e:

logger.error("Failed to click the element with %s" % e)



# 或者网页标题

def get_page_title(self):

logger.info("Current page title is %s" % self.driver.title)

return self.driver.title



@staticmethod

def sleep(seconds):

time.sleep(seconds)

logger.info("Sleep for %d seconds" % seconds)

# coding=utf-8

from framework.base_page import BasePage





class HomePage(BasePage):



input_box = "id=>kw"

search_submit_btn = "xpath=>//*[@id=‘su‘]"



def type_search(self, text):

self.type(self.input_box, text)



def send_submit_btn(self):

self.click(self.search_submit_btn)
这里注意下元素定位写法，=>和base_page.py中find_element()方法元素定位切割有关系，网上有些人写根据逗号切割或者等号切割，在实际使用xpath定位，发现单独逗号或者单独等号切割都不精确，造成元素定位失败。

4. 测试类的写法举例




# coding=utf-8

import time

import unittest

from framework.browser_engine import BrowserEngine

from pageobjects.baidu_homepage import HomePage





class BaiduSearch(unittest.TestCase):



def setUp(self):

"""

测试固件的setUp()的代码，主要是测试的前提准备工作

:return:

"""

browse = BrowserEngine(self)

self.driver = browse.open_browser(self)



def tearDown(self):

"""

测试结束后的操作，这里基本上都是关闭浏览器

:return:

"""

self.driver.quit()



def test_baidu_search(self):

"""

这里一定要test开头，把测试逻辑代码封装到一个test开头的方法里。

:return:

"""

homepage = HomePage(self.driver)

homepage.type_search(‘selenium‘) # 调用页面对象中的方法

homepage.send_submit_btn() #调用页面对象类中的点击搜索按钮方法

time.sleep(2)

homepage.get_windows_img() # 调用基类截图方法

try:

assert ‘selenium‘ in homepage.get_page_title() # 调用页面对象继承基类中的获取页面标题方法

print (‘Test Pass.‘)

except Exception as e:

print (‘Test Fail.‘, format(e))



if __name__ == ‘__main__‘:

unittest.main()


 homepage = HomePage(self.driver)
